內置緊湊，體積小，節省空間；
使用壽命長，節省成本；
操作簡單，使用方便，易學易用
| 波長Wavelength (nm) | 635±5 | 出光孔高度 Aperture Position (mm) | 30 | ||
| 輸出功率 Output Power (mW) | 1~500 | 激光器Laser Head | 尺寸 Dimensions (L×W×H, mm) | 116 x 50 x 45 | |
| 工作方式 Working Mode | CW | 可配電源型號 Integrated Driver Model | VD-I Series / VD-II Series | ||
| 光斑模式Beam Mode | Quasi TE00 | 電源調制External Modulation | 5V TTL / 5V Analogue | ||
| 線寬Spectral Linewidth (nm) | <0.1 | 調制速率Modulating Repetition | 30KHz TTL / 10KHz Analogue | ||
| 偏振方式 Polarization | Line polarization | 制冷方式Cooling System | TEC | ||
| 偏振比Polarization Ratio | >50:1 | 預熱時間Warm-up Time (minutes) | <15 | ||
| 光束質量Beam Quality (M2 factor) | <20 | 工作溫度Operation Temperature (℃) | 18~30 | ||
| 光束發散角Beam Divergence (full angle, mrad) | Square, ~3.0×3.0 | 使用壽命Expected Lifetime (hours) | >10000 | ||
| 光束直徑Beam Diameter at Aperture (mm) | 3.0×4.0 | 保修期Warranty Time | 1 year | ||
| 功率穩定性Power Stability (RMS, over 8 hours) | <5% | ||||
